Description：
It is a 4-inch wall-mounted color screen touch screen that is used with programmable central controller. Suitable for various industrial / commercial occasions such as electrical control, color screen interaction, human-computer interaction, fresh air system, air conditioning system, high-end instruments and other applications.
Feature：
* Built-in 4-inch HD full-color display with capacitive touch glass panel for smooth and easy operation.
* Built-in ARM9 core processor with strong processing performance to meet various computing requirements.
* Support RS485 control. It can interact with central control communication through RS485 messages, and meet the hardware connection requirements of various intelligent appliances and intelligent control.
* The power module is separated from the main panel, and the installation is simple and reliable.
* With UI modification tools, we can change UI pictures.
Specification:
|
Model |
TS-9135 |
|
CPU |
ARM 9 / 400M |
|
RAM |
64M |
|
Flash memory |
16M |
|
Display size |
4 inches |
|
Resolution |
320 × 240 |
|
Chromatic number |
24-bit full color (16.7M colors) |
|
Touch screen |
Single point + gesture capacitive touch screen |
|
Serial port |
RS-485 |
|
Audio |
Built-in buzzer |
|
Button |
Hidden reset button |
|
Bottom box |
86 bottom box |
|
Power supply |
DC 12V (support microusb interface, industrial terminal power supply) |
|
Maximum power |
2W |
|
Operating temperature |
-20 ℃ ～ 70 ℃ |
|
Operating humidity |
RH10% ～ RH90%, no condensation |
|
Storage temperature |
-40 ℃ ～ 85 ℃ |
|
Storage humidity |
≤RH90% |
|
Dimension (LxWxH) |
86 × 86 × 34.9 (mm) |
