Description:
TS-9121 is one 21.5 inch desktop capacitance touch panel, match with programmable central controller, HD resolution 1920x1080P, elegant appearance, support wired connection, particularly applicable to anti -leaks place, capacitance touch mode, the front panel of toughened glass is explosion-proof waterproof splash, support programming pictures, graphics, tests , 2D/3D buttons and so on more humanized interface, support picture in picture display.
Feature：
* The product appearance design is fashionable, beautiful and elaborate, the internal wiring is safe and tidy.
* Capacitance touch screen, anti-scratch glass material, not affected by the pollution source, with eye protection function.
* 15 x 18MM aluminum frame and silver wire drawing effect.
* 3MM toughened glass, and explosion-proof and dust proof.
* With anti-theft device, it can be used in any public scene.
* Wire trunking with tidy wire arrangement
* Sensitivity: It can be reaction for less than 2 ounces force, and it can response for less than 3ms.
Specification：
|
Model |
TS-9121 |
|
CPU |
All winner A83T, 8 core |
|
RAM |
2G |
|
ROM |
8G |
|
Extension Storage Interface |
TF card, SD card |
|
LCD Screen |
|
|
Screen Type |
HD LED screen |
|
Size |
21.5" |
|
Display Area |
476×268mm |
|
Resolution |
1920×1080P |
|
Color |
16.7M |
|
Brightness |
350 nit(cd/m2) |
|
Contrast |
1500:1 |
|
Dot Pitch |
0.48×0.48 |
|
Visual Angle |
Horizontal ±89°, Vertical ±89° |
|
Response Time |
around 8ms |
|
Control-touch Panel |
|
|
Touch Screen |
Capacitance touch screen |
|
Touch Resolution |
4096×4096 |
|
Power Supply Interface |
AC110V~240V, 50~60HZ |
|
USB Interface |
Micro USB, OTG |
|
Video |
|
|
Video Transmission Protocol |
RTSP |
|
Input Mode |
Network cable/WIFI |
|
Network Interface |
100M network interface, RJ45 |
|
Other Specification |
|
|
Speaker |
Buzzer |
|
Speaker Unit |
5W/8W |
|
Working Temperature |
0℃~+40℃ |
|
Working Humidity |
RH20%~RH80% |
|
Material |
Sheet metal + aluminum alloy frame |
|
Metal Back Housing |
5mm toughened glass |
|
Color |
Black+Silver |
|
Dimension(L × W ×H) |
538×329×46mm |
|
Power Consumption |
30±5W |
|
Weight |
About 8.15Kg |
