School Solution - 77 Series Network IP Based PA System

The Details Related Solution Related Cases Related Video Download

null

Product

null


*  With embedded computer technology and DSP audio processing technology.

*  One button ask for help, can call the intercom mic of the duty room.

*  One button ask for alarm,this terminal can be used for alarm task trigger equipment.

*  Built-in microphone with high-sensitivity, with wide area for sound collection。


null

Economic Wall Mounted IP Terminal (with Constant Impedance Amplifier)

T-7705A



*  The equipment is designed with embedded computer technology and DSP audio processing technology.

*  The built-in network IP decoding module can play network music and do one-way paging in real time. The network delay time of acquisition, playback and one-way call function in the system is less than 100 ms.

*  With 4.3-inch TFT true color LCD display, , support to synchronize the server time.



null


POE Ceiling Speaker

T-S708


*   Built-in 1-channel network hardware audio decoding module, supports TCP/IP, UDP protocol, realizes the network transmission of 16-bit CD audio signal.

*   Supporting POE (IEEE 802.3af) power supply mode, only one network cable is needed to connect to POE switch. The construction is simple and convenient, and the maximum connection distance can reach 100 meters.

*   Equipped with DC 24V standby power interface, it is suitable for power supply when power demand is greater than 10W or for non-POE network.


Equipment list


Number
Model
Specifications
Quantity
1
PC
\ 1
2 T-7700RP
IP Network PA System Software
1
3
T-7702A
IP Network Paging MIC (With 7inch Touch Screen)
2
4
T-7770
IP network audio collector terminal
1
5 T-6222
AM/FM Tuner, 1U height
1
6 T-6221
CD Player, USB & SD, 1U height
1
7 T-7723
IP Network Fire Alarm Panel
1
8 T-7731
Industrial Emergency Intercom Terminal
1
9 T-7703
Weatherproof Emergency Intercom Panel (One Button)
1
10 T-7703E
Weatherproof Emergency Call & Service Intercom Panel (Double Button)
1
11 T-7707
IP Network Active Speaker
1
12 T-7705A
Economic wall mounted IP terminal (with 8 Ω amplifier)
2
13 T-7701
IP Network Adaptor
1
14 T-1120DS
Single Channel Class-D Amplifier, 120W
1
15 T-205B
5"+1.5" Coaxial ceiling speaker, 0.75W-1.5W-3W-6W, 100V
1
16 T-774H
4"+1.5" Two way wall mount speaker, 2.5W-5W-10W-20W@100V+8ohm
1
17 T-S7608
POE Wall Amount speaker
1
18 T-S708
POE Ceiling speaker
1
19 T-77120
Rack Mount Network Audio Adapter with RMS 120W power amplifier
1
20 T-S7720
POE Horn speaker
1
21 T-200B
Indoor Pendant Speaker, 3.75W-7.5W-15W, 100V
1
22 T-720A
Outdoor Paging Horn Speaker, 15W-30W, 100V
1







More details pls check: www.itctech.com.cn
