* All core components of the microphone use domestically produced chips, which are safe, confidential, and the core is controllable.
* The microphone adopts a short microphone rod and a high-sensitivity microphone core design, which supports long-distance sound pickup.
* It has intelligent fault detection function to prompt users of AP failure, host communication failure, low signal strength, etc.
* Supports charging via Type-C port and has intelligent indication status.
* SSID can be set via the on-screen interface .
* It has the function of switching display among four languages: Chinese (Simplified and Traditional), English, Russian and French. The PC software supports switching between two languages: Chinese and English.
* It has speech timing and scheduled speech functions.
* With voice control function, the microphone can be turned on intelligently. The voice control sensitivity can be adjusted and the closing time can be set through software.
* Supports sign-in function, which can be set up and initiated through PC software.
* It supports conference voting function, five-key election and three-key voting function, which is flexible and convenient.
* Supports (disc) clock interface display function and can display time.
* It uses 128-bit AES encryption technology and supports WPA/WPA2 wireless security technology to prevent eavesdropping and unauthorized access, providing higher confidentiality of the conference system.
* By adopting wireless transmission technology, only a very short time is needed to set up the venue before carrying out venue activities.
* The delegate machine has the function of applying to speak, and the applicant is approved to speak through the chairman machine.
* It uses a 2.1-inch full-color touch screen.
* It has a 3.5mm headphone jack and can be connected to an external microphone.
* Built-in lithium battery, the battery capacity supports 12 hours of continuous speaking .
Microphone type |
Cardioid directional electret (gold-plated microphone core) |
Frequency response |
80Hz~16KHz |
Microphone input impedance |
1KΩ |
Sensitivity |
- 40 ±1dB (0dB=1V/Pa,at 1KHz) |
Maximum SPL |
1 20 dB (THD < 3%) |
Signal-to-noise ratio |
>80dB(A) |
Crosstalk |
>70dB |
Dynamic range |
>80dB |
THD |
< 0.1 % |
Maximum power consumption |
2 W |
Power supply |
21700 lithium battery power supply |
Charging method |
Connect the charging box to charge via the Type-C interface |
color |
Graphite Gray |
Sign-in function |
Sign-in via physical silicone button |
Display |
LCD screen |
Installation |
Desktop |
Wireless frequency range |
5.15~5.85GHz |
Battery capacity |
9400mAh |
Working time in speech mode |
1 2 hours |
Mic rod size |
240mm |
Base size (L×W×H) |
105 × 126 × 54 mm |
weight |
0.825Kg |
