TS-0318E/ TS-0318EA Conference Chairman/Delegate Unit

The Details Related Solution Related Cases Related Video Download



Feature:


* Digital transmission link, connected to the cascade port of the conference controller for power supply through a network cable, uncompressed audio transmission technology, 48K sampling rate, 80Hz-16kHz bandwidth, perfect sound quality.

* The use of capacitive touch buttons can effectively eliminate the button tapping noise and create a good venue environment.

* Support microphone control via PC software, support voice control function.

* The chairman unit has the priority to turn off the delegate unit that is speaking.

* With TCP/IP protocol suite, it supports ICMP, HTTP, UDP, TCP, IGMP and other protocols.

* Support PING package function.

* Designed with an independent web control page, it can adjust parameters such as microphone ID and microphone sensitivity.

* Support internal voice control function, and the voice control sensitivity is adjustable.

* Support the sign-in function, and support functions such as prohibiting unit sign-in and controlling unit sign-in through the PC software.

* Support web page firmware upgrade function.

* Support IP address sniffing function; the ID number, IP address, MAC address and other parameters of unknown units can be found through PC tools.


Specification:



Model

TS-0318E

Microphone type

Electret Condenser Microphone

Microphone directivity

Cardioid

Frequency response

80Hz~16kHz

Input impedance

1KΩ

Sensitivity

-40±1dB (0dB=1V/Pa, at 1KHz)

Max SPL

120dB(THD>3%)

SNR

>80dB(A)

Crosstalk

>70dB

Dynamic range

>80dB

THD

<0.1%

Maximum power consumption

2.5W

Power supply

Powered by the conference controller

Color

Gray

Sign-in function

Button sign in

Installation method

Desktop installation

Dimension (L×W×H)

100.9×130×54.3mm (excluding the mic pole)

Mic pole length

240mm

Weight

1.15Kg
