TS-W310D/ TS-W310DA Conference Chairman/ Delegate Unit

The Details Related Solution Related Cases Related Video Download


Feature:


* Adopt a 48KHz sampling rate, clear and bright sound, better than the CD sound quality; internal DSP audio processing, no low-frequency popping impact.

* Using advanced processing chip architecture and unique processing algorithm, the microphone power-on connection time only takes 5 seconds.

* Support intelligent detection of faults, prompting users of AP faults, host communication faults, and low signal strength.

* Support charging through Type-C port, support 18W fast charging, with smart indicator status.

* Support setting SSID function through UI.

* Support Chinese and English language switching, and uniformly set through PC software.

* Support the function of speech timekeeping and speech countdown.

* With voice control function, the microphone can be turned on intelligently. Support adjusting the sensitivity of the voice control and setting the closing time through the software.

* Support sign-in function, set and initiate through PC software.

* Support conference voting function, support five-key voting, three-key voting function, flexible and convenient.

* Adopt 128-bit AES encryption technology, support WPA/WPA2 wireless security technology, prevent eavesdropping and unauthorized access, and provide higher confidentiality of the conference system.

* Using wireless transmission technology, venue activities can be carried out with very little time for venue layout.

* The chairman has a priority function to turn off all speaking delegate microphones.

* Adopt a 4.3-inch full color touch display.

* Equipped with a 3.5mm headphone jack for connecting an external microphone.


Specification:

Model

TS-W310D

TS-W310DA

Microphone type

Cardioid directional electret microphone

Frequency response

70Hz~12KHz

Sensitivity

-33±1.5dB (0dB=1V/Pa,at 1KHz)

Max SPL

100dB(THD>3%)

SNR

>80dB(A)

Crosstalk

>70dB

Dynamic range

>80dB

THD

<0.1%

Maximum power consumption

3W

Power supply

18650 lithium battery

Charging method

Connect the charging box through the Type-C interface

Colour

Graphite gray

Sign-in function

Touch screen sign in

Display screen

IPS screen

Dimension

240*136*111.4mm (L*W*H)

Installation method

Desktop

Wireless frequency range

5.15~5.85GHz

Battery capacity

9600mAh

Microphone pole

220mm

Working hour in speech mode

13 hours

Working hour in mixed mode

14 hours
