TS-0230M3/ TS-0230MA3 Conference Microphone

The Details Related Solution Related Cases Related Video Download


Feature:


* Embedded lifting design, neat and elegant appearance, simple and intuitive operation.

* Winding condenser microphone pole, professional super cardioid condenser microphone core, extremely high sensitivity and speech intelligibility, and a ring-shaped red and green dual color indicator light.

* Adopt 48KHz sampling rate, clear and bright sound, better than CD sound quality; adopt internal DSP audio processing, and no low frequency "pop" noise.

* Support internal feedback suppression function, effectively prevent squealing.

* Support 5-band EQ adjustment function, sound effects can be adjusted according to different speakers' voice characteristics to achieve the perfect effect.

* The chairman has a priority function and can turn off all delegate microphones that are speaking.

* Support voice control function, and adjustable sensitivity of the voice control. In the voice control mode, both the chairman unit and the delegate unit can turn on the microphone by voice control. After the delegate microphone is turned on, if no one speaking lasts for 30 seconds (default), the microphone will be automatically turned off, while the chairman is not limited by this.

* Using 100M network transmission to achieve hand-in-hand cascading, long-distance transmission will not have any impact on sound quality.

* Support intelligent control of the microphone, the microphone can only be turned on when it is lifted to the top, and will be automatically turned off when it is lowered.

* The conference controller can realize command issuing and control the unit lifting and lowering.


Specification:


Model

TS-0230M3/ TS-0230MA3

Microphone type

Cardioid pattern electret condenser microphone

Frequency response

80Hz-16KHz

Microphone input impedance

680

Sensitivity

-41±1.5dB (0dB=1V/Pa,at 1KHz)

Max SPL

120dB

SNR

>80dB(A)

Dynamic range

>80dB

THD

<0.1%

Power consumption

2W

Connector

6-pin aviation connector

Power supply

Controller power supply DC36V/3W

Microphone port

2 sets of six-pin aviation ports, realize the hand-in-hand connection of multiple units

Power supply mode

Mains 110~240V 50/60HZ

Color

Silver

Sign-in function

Physical button sign-in

Weight

About 5.5 Kg

Microphone pole

409mm

Size

160×70×717mm (L×W×H)

Installation method

Embedded installation

Desktop opening size (through hole)

147×62mm (L×W)

Panel sinking size

161×71×4mm (L×W×D), rounded corner: 4×R4



Φ9.7 microphone core graphics coordinates

Frequency response curve


null


Microphone Cardioid Pattern


null


Opening size drawing

null
