KF-Y12 Professional Full Range Speaker

The Details Related Solution Related Cases Related Video Download



Description:


It is used in public cinemas, private cinemas and various high-end occasions.


Feature:


* Adopt a 12-inch woofer and a 1.75-inch tweeter.

* The cabinet is made of 15mm medium density fiberboard, and adopts water-based paint treatment, novel appearance design, high-grade and wear-resistant.

* The tweeter is flexible and adjustable to easily adapt to different listening environments; it provides natural timbre, and huge dynamics, bringing the audience an immersive experience.

* The mesh cover adopts the cotton attachment process to prevent dust or liquid from entering, so as to protect the speaker and prolong the service lifespan.

* Professional speaker sockets and plugs with good electrical characteristics.


Specification:


Model

KF-Y12

Rated power

350W

Peak power

1400W

Nominal impedance

Frequency range

40Hz -19KHz

Sensitivity

95.5dB (1M/1W)

Maximum SPL (rated/peak)

121B/127dB

Woofer

12" woofer × 1

Tweeter

1.75" tweeter × 1

Coverage angle (-6dB)

100°(H) 50°(V)

Net weight

22kg

Dimension (H×W×D)

859×406×320mm
