Description：
The linear array speaker is combined of tweeters and woofers. Using imported birch materials, its housing is small in size, light in weight, and wear-proof. It consists of two 8-inch(200mm) neodymium magnetic woofer drivers and one 75mm neodymium magnetic tweeter driver, providing sounds with the features of long distance, high sensitivity and strong penetration. The frequency divider in precise design can optimize the power response and the vocal MF performance. The combination of hoisting installation and linear array design, allows 0-14 degrees of adjustable coverage area of the speaker, and has the advantages of compact combination, lightweight, and convenient engineering assembly.
Feature：
* Plug and play, user-friendly operations.
* Professional hanger combination, simple hanging method, convenient engineering assembly.
* Strong power, smooth and soft sounds, high reduction.
* Applicable to large multi-function halls, theaters, stadiums, etc.
Specification:
|
Model |
LA-2800K |
LA-1800K |
|
Type |
2-frequency linear array full-range speaker |
Woofer |
|
Rated power |
600W (AES) |
800W (AES) |
|
Peak power |
2400W |
2400W |
|
Nominal impedance |
8Ω |
8Ω |
|
Frequency range |
65Hz-20KHz |
40Hz-400Hz |
|
Sensitivity |
103dB (1M/1W) |
101dB (1M/1W) |
|
Maximum SPL(rated/peak) |
131dB/137dB |
128dB/135dB |
|
Woofer |
8" ×2 |
18" ×1 |
|
Tweeter |
77mm(3") compressed driver×1 |
/ |
|
Horizontal coverage angle (-6dB) |
110° |
/ |
|
Vertical coverage angle (-6dB) |
10° |
/ |
|
Net weight |
24.5Kg |
35.5Kg |
|
Size(H ×D ×W) |
(250+190)×380×700 mm |
550×710×700mm |
