Description:
It works with the professional amplifier and audio processors. It can be used as a monitor speaker in large conference halls and multi-function halls, etc.
Feature:
* Use a mid-woofer and an annular polyethylene diaphragm compressed tweeter.
* 15mm plywood housing, light weight, wear-resistant spray paint treatment, external hard hexagonal iron mesh, and dust-proof cotton inside.
* The frequency divider in precise design optimizes the vocal MF performance.
* The cabinet has a polygonal structure, and the monitoring angle can be adjusted according to different venues.
Specification:
|
Model |
TS-610T |
TS-612T |
TS-615T |
|
Impedance |
8Ω |
8Ω |
8Ω |
|
Frequency response |
60Hz-20KHz |
50Hz-20KHz |
45Hz-20KHz |
|
Rated power |
300W |
400W |
500W |
|
Peak power |
1200W |
1600W |
2000W |
|
Sensitivity |
98dB/W/M |
99dB/W/M |
100dB/W/M |
|
Max SPL(rated/peak) |
123dB/129dB |
125dB/131dB |
127dB/133dB |
|
Coverage angle |
(H)80° (V)60° |
(H)80° (V)60° |
(H)90° (V)70° |
|
Tweeter |
1.4" compressed tweeter ×1 |
1.7" compressed tweeter t×1 |
1.7" compressed tweeter ×1 |
|
Woofer |
10" woofer ×1 |
12" woofer ×1 |
15" woofer ×1 |
|
Size (H×W×D) |
340×510×380mm |
380×585×440mm |
395×690×465mm |
|
Weight |
17.5Kg |
20.5Kg |
26.5Kg |
