Feature:
* Color: 3*40W (RGBW) red, green, blue and white LED.
* Function: 1 water glass column, independent rotation, forward and backward stepless rotation, and adjustable speed.
* Dimming: 0-100% linear adjustment.
* Strobe: electronic strobe, 0-25 times/sec (built-in pulse stroboscopic effect).
* DMX512 port program update, convenient and fast software update via DMX data cable.
* Over-temperature protection function: built-in NTC temperature control function; when the LED is overheated, the output power will be intelligently reduced.
* LCD blue screen display. The lamp usage time, software version number and others are displayed.
Specification:
|
Model |
TL-LT103 |
|
Input voltage |
AC 110-240V 50/60Hz, 120W |
|
Light source |
3 OSRAM 40W (RGBW) red, green, blue and white LED |
|
Average lifespan |
50000H |
|
Color temperature |
7500K |
|
Beam angle |
22.5° |
|
Control mode |
Comply with the international standard DMX512 signal control protocol, 3-core (5-core optional) DMX512 signal interface; master-slave synchronous control mode, support RDM protocol and program online update function |
|
Operation mode |
DMX mode, user program mode, built-in program mode |
|
Channel |
5/9 channels |
|
Fixture material |
High-strength extruded aluminum + die-cast aluminum alloy end cover |
|
Protection level |
Protection IP67 |
|
Working temperature |
-20℃～45 ℃ |
|
Fixture size (L×W×H) |
1000×140×174mm |
|
Package size (L×W×H) |
1075×250×255mm |
|
Gross weight |
9.4kg |
|
Net weight |
5.5kg |
