Descriptions:
*Paging to all zones in the system.
*Enter into or exit the emergency mode.
*Support fireman mic recording function.
*Support self detection in paging conflict status.
*Can display the EVAC/ALERT audio source status.
*Same priority of fireman mic and PTT mic.
*Support power supplied by 24V DC and network cable.
*Support max 4pcs fireman mics.
Specifications:
|
Model |
VA-WFM |
|
Power supply |
Voltage ~ DC 24V battery |
|
Mic input |
24V network port |
|
Sensitivity |
5MV±0.5mV |
|
Frequency response |
200Hz~10kHz |
|
Input impedance |
≥1kΩ |
|
CAN interface |
CAN interface of remote mic Baud rate of |
|
100bps Support up to 4 fireman mic |
|
|
Dimension(mm) |
260×200×100mm |
|
Net weight |
2.3Kg |
|
Installation |
Wall mounted |
|
Color |
Grey |
|
Operating temperature |
+5℃~ +40℃ |
|
Storage temperature |
-20℃ ~ +70℃ |
|
Relative temperature |
<95% |
