VA-6500 CF1 FAS Short Circuit Board PA System

The Details Related Solution Related Cases Related Video Download


Feature:


* Collect the external input status  signals and upload them to the interface controller.

* Receive the control commands from the interface controller to control the executing actions of the external output interface.

* Receive the scheduling commands to collect audios and play them to the designated zones.

* Receive the scheduling commands to output the corresponding audio signals.

* Report the working status of the equipment: online status, failure status, etc.


Specification:


Model

VA-6500

Network interface

RJ45*1, 10/100 Mbps adaptive, IGMP, TCP/IP protocol

External input interface

4-channel programmable triggering inputs

External output interface

4-channel  relay programmable outputs

Audio input

Balanced/unbalanced * 1, ± 0. 385 V (balanced), 0.775 V (unbalanced)

Audio output

Balanced output * 1, ± 0. 375 V, TDH 0.1%, 80 ~ 16kHz

Supporting board quantity

A maximum of 8

Size

263 × 124 × 30

Weight

0.3 kg
