T-7752 IP Terminal

The Details Related Solution Related Cases Related Video Download


Description:


T-7752 is suitable for schools (special education industry), office buildings, conference centers, alarm centers, station restrooms and other places.Using the network digital transmission, play the background music set in the system, timer ringing task, audio source collection, one-way call and other functions.



Features:


* Wall-mounted design, compact size, aluminum alloy integrated structure design, exquisite and beautiful.

* 3.4-inch LCD display, clear at a glance, with infrared remote control function, easy to operate.

* The equipment adopts industrial dual-core processing chip (ARM+DSP).

* Built-in network IP decoding module can play network music and one-way call function in real time;The network delay time of acquisition and play and one-way call function in the system is less than 100ms.

* Built-in VOD acquisition module, which can realize real-time VOD function of network media library audio.

* Built-in 2×30W (MAX) digital power amplifier, low heating efficiency, CD level perfect sound quality.

* It is equipped with 1 route input interface and 1 route output interface, which is suitable for on-site local sound amplification and broadcasting function.

* Extensible 2.4G wireless audio module, to achieve 2.4G wireless microphone for local amplification.

* Extensible connection with Bluetooth receiver to receive Bluetooth audio for local sound amplification.

* Priority features:

1) Network alarm is the highest priority.

2) Local MIC and AUX are of the same level and have priority over network background music.

11. Compatible with router, switch, bridge gateway, Modem, Internet, 2G, 3G, 4G and other arbitrary network structure.

* Support the broadcast system to upgrade the firmware remotely to the terminal, no need to upgrade locally to the terminal, and reduce the work intensity of maintenance personnel.

* Two circuit short circuit output (red, green). The short circuit output of the equipment can provide short circuit switch signal, and the short circuit signal is controlled by the lighting mode of IP software.

* Customers can purchase more "external control accessories" light prompt components, or provide corresponding components by themselves according to the recommended scheme.

* External control accessories



Name

Specifications

quantity

Power adapter

GM50-240200-F- Leakage current 0.07mA(without plug -

core to wire 350mm-)

1

Other electronics

Lights-S60L-DC24V-R

1

Other electronics

Lights-S60L-DC24V-G

1

Iron lining

MM-01496-V0.1(Sand Black RAL9004)

2


Specifications:


Model

T-7752

Network Interface

Standard RJ45

Support Protocol

TCP/IP、UDP

Audio Format

MP3

Sampling Rate

8KHz~48KHz

Transmission Rate

100Mbps

Audio Mode

16 bit CD sound quality

Size of display screen

3.4 inch

Display type

128×64 dot-matrix display screen

Operating mode

Infrared remote control

Remote control distance

10m, straightbarrier-free

Output power

2×30WMAX

THD

≤1%

Frequency response

80Hz~16KHz  +1/-3dB

SNR

>65dB

AUX input sensitivity

350mV  Press the wire terminal with

 Industrial standard

MIC input sensitivity (Non-Balance))

5mV

Short circuit output (red、green)

DC30V 3A (dry node)

Operating Temperature

5~40

Operating Humidity

20%~80% relative humidity, non-condensing

Power input

~190-240V 50-60Hz,power adapter DC 24V

Power Consumption

≤70W

Dimension

170×134×45mm

Net weight

0.5Kg
