Description:
It works with the professional amplifiers and audio processors, forming a set of high-end outdoors water-proof professional sound system with perfect sound effects and outstanding vocal performance. It is suitable for various places with high humidity, outdoor performances, etc.
Feature:
* Adopt a water-proof woofer and an annular polyethylene diaphragm compressed tweeter.
* 15mm plywood housing, iron mesh cover, and dust-proof net cotton inside.
* The cabinet adopts imported polyurea coating, waterproof painting treatment and water-proof speaker unit, and can be outdoors waterproof all weather.
* Multiple screw hoisting holes, a pole socket with a diameter of 35mm, various installation methods.
Specification:
|
Model |
TW-10 |
TW-12 |
TW-15 |
|
Impedance |
8Ω |
8Ω |
8Ω |
|
Frequency response |
60Hz-20KHz |
55Hz-20KHz |
50Hz-20KHz |
|
Rated power |
300W |
400W |
500W |
|
Peak power |
1200W |
1600W |
2000W |
|
Sensitivity |
99dB/W/M |
100dB/W/M |
101dB/W/M |
|
Max SPL(rated/peak) |
124dB/130dB |
126dB/132dB |
128dB/134dB |
|
Coverage angle |
(H)90° (V)80° |
(H)100° (V)80° |
(H)100° (V)80° |
|
Tweeter |
1.4" compressed tweeter ×1 |
1.7" compressed tweeter ×1 |
1.7" compressed tweeter ×1 |
|
Woofer |
10" woofer ×1 |
12" woofer ×1 |
15" woofer ×1 |
|
Size(H×W×D) |
490×330×330mm |
570×370×380mm |
690×460×450mm |
|
Weight |
17.5Kg |
24.5Kg |
30.5Kg |
