Model

T-B60DTB

 T-B120DTB

T-B240DTB

T-B350DTB

T-B500DTB

T-B650DTB

Output

4-16Ω, 100V

RMS Power

60W

120W

240W

350W

500W

650W

Input Sensitivity

& Impedance

MIC1, 2, 3, 4 input: 5mV/600Ω balanced European connection terminal

AUX1, 2 input: 350mV/10KΩ unbalanced RCA connection terminal

EMC input: 775mV/10KΩ unbalanced European connection terminal

Output Sensitivity &

Source Impedance

MIX OUT: 1000mV/470Ω, unbalanced RCA connection terminal

Tone

Bass: ±10dB at 100Hz;

Treble: ±10dB at 10KHz

Frequency Response

80Hz~16KHz(+1dB,-3dB)

SNR

MIC1, 2, 3: 66dB; AUX1, 2: 80dB

THD

Less than 0.5%( at 1KHz, 1/3 rated power)

Phantom Power Supply

48V (±2V)

Mute Control

MIC 1 priority over MIC2-4, AUX1-2 audio input;

EMC has highest priority

Channel Crosstalk

Attenuation

≥50dB

Heat Dissipation

Flank in and rear panel out to force fan cooling, fan starts when amplifier turned on, infinitely variable speed

Protection

Over-heat, overload, short circuit

Power Supply

~220-240V /50Hz

Power consumption

120W

180W

300W

500W

650W

850W

Dimension

484×300×44mm

Weight

3.5 Kg

3.7Kg

3.8Kg

4.0Kg

4.1Kg

4.3Kg
