Unit Composition

2 x 10-inch 75-core ferrite magnet imported diaphragm woofers, 1 x 75-core neodymium magnet imported

composite diaphragm tweeter. 1 x 51-core 8-inch ferrite magnet midrange (built-in three-way single-drive).

Frequency Response (+/-3dB): 42Hz-19.60kHz

Coverage Angle (-6dB)

100 degrees/10°

Sensitivity (1m/1W)

103dB

Output SPL

138dB

Rated Impedance

8 ohms

Power

800W

Recommended Amplifier Power

1000-1300W

Interface Type

NL4FC/Built-in single-drive aviation plug (optional)

Net Dimensions (HxWxD)

30cm x 72cm x 40cm

Package Dimensions (HxWxD)

40cm x 82cm x 50cm

Net Weight

37kg

Total Package Weight (kg)

40kg
