Feature：
*Supports customized display of program content through the information release system, supports playback of pictures, videos, audio, files and other material resources, and supports multiple audio and video encoding formats, picture formats, and file formats.
*The program supports setting playback mode and schedule, such as periodic playback, continuous playback, interstitial playback, idle playback, etc. The validity period of the program can also be set.
*The device supports timed power on/off tasks, timed restart tasks, and timed screen off tasks, which can be set to single, daily, custom and other modes.
*The device supports interstitial subtitles (marquee), and supports customizing text content through the information release system, including text size, text background, text color, scrolling speed, and display position.
*The device supports adjusting playback volume, device restart, device time synchronization, etc.
*The screen is light-resistant, 4K high-definition display, with high brightness and contrast.
*The device supports touch interaction and supports vertical vertical screen display of promotional materials.
Specification：
|
Display screen |
55-inch LCD touch screen, supports 20-point infrared touch |
|
Resolution |
4K |
|
Display ratio |
9:16 |
|
Display area |
680.4×1209.8mm |
|
Brightness |
300 cd/㎡ |
|
Contrast |
≥1200:1 (Typ.) |
|
Total number of colors |
16.7M colors |
|
Refresh rate |
50/60Hz |
|
Response time |
8(Typ.)(GtoG) |
|
Viewing angle |
178 degrees horizontal, 178 degrees vertical full viewing angle |
|
Operating system |
Android 11.0 |
|
Processor |
Quad-core 64-bit processor, up to 2.0GHz |
|
Running memory |
4G |
|
Storage memory |
32G |
|
Touch recognition |
≥1.5mm (opaque objects such as fingers and stylus) |
|
Service life |
≥60,000 hours |
|
Anti-light interference |
Normal use when strong light changes such as sunlight, incandescent lamps, fluorescent lamps, etc. |
|
Surface hardness |
Mohs 7-level explosion-proof tempered glass |
|
Network |
Support Ethernet/wireless WiFi, 10M/100M adaptive Ethernet |
|
Interface |
USB2.0×1, USB3.0×1, HDMI output×1, RJ45×1, 3.5mm audio×1 |
|
Speaker |
2×10W |
|
Input power |
AC110-240V 50/60Hz |
|
Power consumption of the whole machine |
≤110W |
|
Standby power consumption |
≤1.5W |
|
Operating temperature |
0℃-38℃ |
|
Operating humidity |
10%-95% |
|
Storage temperature |
0℃-40℃ |
|
Storage humidity |
10%-95% |
|
Dimensions of the whole machine (W×D×H) |
731.8×500.4×1900mm |
|
Net weight (bare machine) |
57kg |
|
Gross weight (packaging) |
58.5kg |
