* Optical system: Made of high-temperature resistant and high-transmittance optical glass (3-layer coating), φ140mm Fresnel lens.
* Dimming: 0-100% electronic linear dimming, jitter-free smooth dimming technology.
* Strobe: 0-25 times/second electronic strobe, speed adjustable, built-in random strobe or pulse strobe.
* Focusing: Linear electric focusing.
* Color mixing system: Warm white + cool white 2 colors can be linearly mixed to adjust the color temperature.
* Display interface: 1.5-inch blue screen LCD display; equipped with 3 manual knobs.
|
Input voltage |
AC 110-240V, 50/60Hz |
|
Rated power |
220W |
|
Power factor |
PF≥0.98 |
|
Light source |
200W LED (CW+WW) |
|
Average lifespan of light source |
50000H |
|
Color temperature |
2700K-6500K |
|
Color tolerance |
SDCM≤3 |
|
Luminous flux |
5016lm |
|
Color rendering index |
Ra≥97 |
|
Beam angle |
15°-65° |
|
Control method |
DMX512 protocol, RDM protocol, built-in master-slave mode, manual control mode |
|
Channel mode |
Standard mode 4CH |
|
Housing material |
die-cast aluminum |
|
Power interface |
1 power input interface, 1 power output interface |
|
Signal interface |
1 DMX512 input interface, 1 DMX512 output interface |
|
Working environment temperature |
-10℃-45℃ |
|
Protection level |
IP20 |
|
Product dimensions (L×W×H) |
570×285×435mm |
|
Packing dimensions (L×W×H) |
610×335×395mm (carton) |
|
Gross weight of packaging |
13Kg |
|
Product net weight |
10.9Kg |
