Description:

This product uses intelligent control technology, takes intelligent terminal as the application concept, and adopts original rail design. With one-key operation, it can automatically complete the startup, LCD screen rise, elevation and other actions. The desktop is beautiful and atmospheric, and it is space-saving. It is very convenient to use and has anti-theft, dust-proof, and desktop beautification functions. It can be widely used in conferences, office hotels, teaching studios and other occasions to meet the needs of customers for diversified system expansion and office environment automation. It is your ideal assistant in office and teaching.

Features:

* The dual-screen paperless smart desktop adopts a dual-screen design . The front screen is a 15.6-inch high-definition LCD screen and the back is equipped with an 11.6-inch secondary screen . The back screen is driven by the serial port and is matched with a paperless conference terminal. It can display the patterns required for the meeting and the names of the meeting guests, perfectly realizing the powerful interactive paperless conference functions.

* The touch ultra-thin high-definition display screen and the lifter are integrated into a design with no exposed connecting wires, no connecting back panel, and no exposed screws, ensuring that the lifting display touch screen is beautiful as a whole.

* The equipment adopts an all-aluminum structure, high-quality aluminum materials plus CNC precision carving processing, the display frame and chassis are all made of aluminum alloy, making the overall equipment exquisite, lightweight, beautiful and atmospheric.

* The surface treatment of the equipment is anodized, with bright color.

* The device panel is only 3mm thick and 70mm wide, taking up little space. It is lighter and takes up less space than traditional lifts. The product weighs only one-third of a conventional lift, reducing transportation costs and putting less pressure on the conference table.

* The transmission structure is specially processed to minimize noise. The product transmission method uses high-quality tensile belts, high-precision slider guides and linear bearings, and AC reduction motors as driving power; the central control protocol has strong compatibility and is compatible with all control hosts. After the control device rises, the screen automatically powers on, and after it falls, the screen automatically powers off, which is energy-saving and environmentally friendly.

* It uses a 15.6-inch ultra-thin LCD touch screen display with a resolution of 1920 × 1080P. The display effect is clear and bright, and the adjustable backlight design can prevent fatigue caused by excessive brightness or darkness.

* It supports two signal inputs, HDMI and VGA. When only one signal is input, the screen will automatically identify the signal. When two signals are input at the same time, they can be manually switched through the panel buttons. When there is no signal input, the screen automatically enters power saving mode.

* The equipment can be centrally controlled through the central control software, and the host can be controlled through the RS232/RS485 protocol. All indoor equipment can be raised or lowered with one button.

* The built-in loop-through output power socket can supply power to the terminal, reducing the wiring of the terminal power socket and making the wiring on the project site neater and more beautiful.

* The desktop panel has a USB interface, which can be used to browse or upload files by connecting a USB flash drive.

Specifications:
