Description:

A powerful and flexible digital mixing console. Equipped with a 15.6-inch touchscreen, it features built-in parametric equalizer, compressor, noise gate, and other DSP processing functions. It also boasts 2-channel FX effects, automatic mixing, feedback suppression, and other practical features. Supporting multi-terminal control and scene storage, it is suitable for various applications such as conference rooms and small lecture halls.

Feature:

* It features a 15.6-inch 1920×1080 pixel color TFT capacitive multi-touch screen that can display information such as menu bar, channel level, gain , device name, USB connection status, temperature, and runtime in real time.

* It features a panel lock function, supporting screen lock/unlock , requiring a password to unlock to prevent accidental operation; and also supports changing and resetting the password .

* It features 12 microphone/line inputs (XLR, supporting 48V phantom power and can be switched on and off individually), 2 line stereo inputs, 1 USB stereo input , and 1 USB sound card stereo input, with sensitivity that can be flexibly adjusted according to different audio sources.

* It features 2 main outputs (XLR), 6 AUX auxiliary outputs (XLR), 1 stereo monitor output (1/4" TRS), and supports sound card L/R recording output.

* It features USB recording and playback capabilities, supporting playback of MP3, M4A, AAC, WAV, FLAC, AMR, and OGG audio formats, and recording of WAV audio formats.

* It features a USB sound card, allowing users to connect to a computer via a USB cable and synchronize audio between the computer and the device .

* It has one RS-485 interface , which supports connection to the central control system via the 485 protocol to realize remote control of the device, including control of input channel gain, mute setting and mute cancellation , output channel gain, mute setting and mute cancellation , USB playback previous track, next track, start playback, pause playback, playback mode switching , and 1-99 scene mode switching functions.

* It has one RJ45 Ethernet interface, and PC software can centrally manage one or more devices via a local area network.

* It features equalizer functionality: each input has a 12-band parametric equalizer; each output can be selected as either a 12-band parametric equalizer or a 31-band graphic equalizer ; the parametric equalizer supports three types: high-pass , low-pass , and peak filtering, while the graphic equalizer supports single-point bandwidth adjustment.

* features a crossover function and offers three filter types: Bessel, Linkwich-Rayleigh, and Butterworth. It supports multiple slope settings of 6/12/18/24/32/40/48 dB/oct, and the filter is adjustable across the entire frequency band.

* It has a compressor function, which can effectively compress the dynamic range of the signal and control the size of the output signal.

* It has a limiter function, which can limit the amplitude of the output signal and prevent damage to the sound reinforcement equipment due to excessive signal.

* It features a noise gate function, which can eliminate background noise according to the actual usage environment and improve speech clarity.

* It features a delay function, supporting delay adjustment from 0 ms to 2000 ms, used to coordinate the timing of each output signal and ensure audio synchronization for the listener.

* It features a built-in 2-channel FX effects engine processor, supports dual-channel output, and offers 17 effect types that can be selected according to different application scenarios to create a rich listening experience.

* The system has extremely low processing latency, with end-to-end audio latency ≤ 2.3ms.

* It supports 6 automatic mixing functions, including gain-sharing mixing and gate automatic mixing modes. Each input channel can be independently set to participate in the mixing to adapt to different scenario needs.

* Built-in feedback suppressor function , supporting notch filtering, frequency shifting, and dynamic/fixed (24 points) to effectively suppress howling.

* It has a built-in signal generator that can produce three types of noise: white noise, sine wave, and pink noise . The volume is adjustable and it can be assigned to aux1-6 and MAIN channels .

* It has bus grouping processing function , with 4 built-in DCA groups, 4 silent groups and 6 SUB groups.

* With built-in monitoring functionality, users can monitor the input channels, effects channels, group channels, and output channels , and adjust the monitoring volume .

* It supports exporting/importing scene files via USB flash drive, and the device can store 99 user scenes for easy and quick scene switching.

* Supports channel duplication and channel integration functions.

* It supports two control methods: PC client and Android tablet, enabling device login, scene switching, input/output configuration, and channel settings ; it also supports multiple devices logging in simultaneously and maintaining data synchronization.

* It features four customizable physical buttons that can be set to " scene recall" or " mute group " control for flexible operation .

* It has four physical shortcut buttons ( main interface shortcut button , menu shortcut button , settings shortcut button , and scene shortcut button ), which can directly access the corresponding interface with one click and simplify the operation process .
