Model

TV-820W

Operating system

Windows7/8/8.1/10; mac OS 10.12 and newer versions

Frame rate

Windows7: 1920x1080@20fps/1366x768@20fps; Windows8(8.1)/OSX: 1920x1080@30fps/1366x768@30fps; Windows10: 1920x1080@30fps/1366x768@30fps

Maximum connection number

1 receiving terminal can be connected to 8 transmitting terminals at the same time

Maximum connection distance

12m

Transmission delay

65ms

Input and output interface

1×USB 2.0

Operating frequency

2.4GHz/5GHz

Working temperature

0℃~40℃

Storage temperature

-20℃~60℃

Relative humidity

10%~90%

Power supply

DC-5V

Power consumption

0.85W

Net weight

0.1kg

Gross weight

0.25kg

Fixture size

178.7×77×21.3mm (L×W×D)

Package size

210×111×44mm (L×D×H)
