Description:
* Made of high-quality plywood, the cabinet is characterize by small size, light weight, and wear-resistant spray paint treatment.
* It is composed of 2 5" neodymium magnet mid-woofer units and 1 1.73" neodymium magnet tweeter driver with high sensitivity.
* The precisely designed crossover optimizes the power response and the mid-frequency expressiveness of the vocal part.
* The hoisting combined linear array design allows the speaker coverage area to be adjusted in the range of 0-10 degrees.
* The combination of professional pendant parts, simple and quick pendant method, easy to assemble in sound engineering.
* With a wide range of applications, it works with TA professional amplifiers and audio processors. It is suitable for reinforcent in conference rooms, multi-function halls, and banquet halls.
Specification:
|
Model |
TK-L205 |
|
Type |
2-channel linear array speaker |
|
Rated power |
200W |
|
Peak power |
800W |
|
Nominal impedance |
8Ω |
|
Frequency range |
65Hz-20KHz |
|
Sensitivity |
100dB |
|
Maximum sound pressure level (nominal/peak) |
123dB/129dB |
|
Woofer |
5"woofer*2 |
|
Tweeter |
1.73" compressed driver*1 |
|
Horizontal coverage angle (-6dB) |
120° |
|
Vertical coverage angle (-6dB) |
10° |
|
Weight |
9.2kg |
|
Dimension (H×W×D) |
(167+118)×455×315mm |
Model
TK-S125
Type
Subwoofer
Power
500W
Peak power
2000W
Nominal impedance
16Ω
Frequency range
45Hz-500Hz
Sensitivity
99dB
Maximum sound pressure level (nominal/peak)
126dB/132dB
Woofer
12"*1
Weight
20kg
Dimension (H×W×D)
360×455×400mm
