TL-LT702 30W Laser Light

The Details Related Solution Related Cases Related Video Download


Specification:


Model

TL-LT702

Input voltage

AC 110-240V 50/60Hz, 1000W

Laser brand

Japan Nichia Diode Chip/[G30W-532NM]

Laser lifespan

≥10000 hours (it is better to be used in indoor environments)

Laser class

Class IV

Scan angle and graphics speed

+/-30 degree-DT40K Galvo scanner

Quality dielectric film reflectivity

>98%

Laser control signal voltage range

± 5V

Divergence angle

<1.6mrad (full angle)

Laser spot

<6.5mm

Modulation mode

TTL/analog switching

Graphic control mode

Work with the American pangolin software FB4+DMX control hardware to realize the programming effect

Housing design

Lightning protection, over-current and over-voltage protection, leakage protection, moisture-proof, and anti-interference optical path sealing, three-layer structure, completely sealed optical path layer

Software control

All ILDA signals are converted by electronic switches

DMX channel

International standard DMX protocol channel (15CH)

PC-linked software interface

International unified standard DB-25 input and output

Cooling method

Air cooling

Laser temperature control

TEC dual temperature control

Protection level

Protection IP58

Working temperature

-50℃~50℃

Fixture size (L×W×H)

460×460×250mm with handle 420mm

Package size (L×W×H)

670×620×420mm (flight case)

Net weight

42kg
