Feature:
* Various preset dynamic virtual pattern effects, bidirectional rotation, adjustable speed.
* Various preset static virtual pattern effects.
* The foreground color of the dynamic/static virtual pattern is optional, the color temperature is adjustable, and it supports dimming.
* The background color of the dynamic/static virtual pattern is optional, the color temperature is adjustable, and it supports dimming.
* Dimming system 0~100% smooth linear LED dimming.
* Support horizontal/vertical rotation and correction.
* RGBW stepless color mixing.
* Uniform light spot, pure color mixing, delicate and full light color.
* Built-in 33 color macro function effects.
* 7 built-in self-propelled programs.
* The screen is equipped with a battery, and can be used for the address code setting and other settings in the menu.
* With DMX signal monitoring indicator.
* The screen can be flipped by 180°.
* Automatic screen off function.
* High-efficient and noise-free five-fan natural cooling system, cooling aluminum/copper + liquid/fan.
* Support the display and management of the working temperature of the light.
* The over temperature protection function can reduce the lamp bead power to ensure the normal use.
Specification:
|
Model |
TL-LT821 |
|
Input voltage |
AC110V-240V 50/60Hz, 960W |
|
Light source |
19*40W LED |
|
Color temperature |
2800K-3200K tungsten lamp simulation effect, 3200K-8000K linear color temperature adjustment |
|
Average lifespan |
20000H |
|
Beam angle |
5.5-50° |
|
Control mode |
International standard DMX512 signal; DMX512, master-slave, voice control or self-propelled operation, Art-NET control (optional) built-in imported DMX wireless receiver (optional) |
|
Channel |
14/20/30/37 channels |
|
Power supply |
Waterproof power line input and output, with switch and fuse holder |
|
Signal input |
Input signal isolation protection function to ensure stable signal transmission without interference |
|
Network interface |
Waterproof RJ45 Ethernet connector input and output (optional) |
|
Signal line |
Waterproof signal line input and output |
|
Screen |
2.4-inch HD TFT LCD touch screen |
|
Working temperature |
-25°C-45°C |
|
Protection class |
IP65 |
|
Fixture size (L×W×H) |
324.5×444×591mm |
|
Package size (L×W×H) |
530×650×700mm |
|
Gross weight |
27kg |
|
Net weight |
24kg |
Please leave a message if necessary, we will contact you as soon as possible!
