T-2120UC/T-2240UC/T-4120UC/T-4240UC 2/4 Channel Matrix Digital Mixer Amplifier

The Details Related Solution Related Cases Related Video Download

ITC matrix digital mixer amplifier of new UC series, with higher efficiency, is ideal for commercial sound system.




null




Description


It meets thedemands of emerging markets to provide high-quality equipment at affffordable prices. The UC series amplififiers enjoy two outputs of 4R/100V and multiple functions, which are applicable worldwide. The series combines many functions for convenient and flflexible usage, including Bluetooth and USB media players; low impedance function (4 ohm/8 ohm) and high impedance output (100V); each output channel is equipped with separate bass and treble control. It is suitable for clubs, stadiums, shopping centers and other broadcasting systems on demand of multi-channel high-power amplififier.




Feature


* 120W/240W constant impedance/voltage high performance digital amplififier (4-16R/100V) with 4 channel outputs.

* Built-in MP3 recording function.

* 6-channel independent volume control.

* 6-channel audio sources can be input to each channel output through matrix confifiguration.

* MIC1-4 input with adjustable gain.

* 4-channel outputs support independent amplififier tone adjustment.

* Support 4 remote microphone inputs.

* Built-in MP3 (U disk/SD card) player function.

* Built-in FM radio function.

* Adopt high-grade OLED screen.

* 4-channel outputs support the remote panel control.

* Distortion, protection, signal, output status indicator.

* MIC 1-4 channels support phantom power.

* 1-4 Channels enjoy priority and mixing selection function.

* Enjoy priority input port of EMC alarm sound source.

* ALARM port to play the specifified alarm track.

* Built-in Bluetooth function and high-gain Bluetooth antenna to connect to mobile phones / computers.

* 4-channel MUTE ports can be connected to the fifire control port.

* Priority: MUTE>EMC>REMOTE MIC> MIC1-4>MIC5-6 LINE5-6.




Specification


Model
T-2120UC
T-2240UC
T-4120UC
T-4240UC
Output terminal
4-16Ω, 100V
Output power
2*120W
2*240W
4*120W
4*240W
Input sensitivity & impedance

MIC1-6 input: 5mV-350MV±40MV/600Ω

AUX1-4 input: 350mV±40MV/10KΩ unbalanced RCA connection terminal

EMC input: 775mV/10KΩ unbalanced European connection terminal

Output sensitivity & source impedance
OUT1-4 OUT: 1000mV/470Ω unbalanced RCA connection terminal
Tone

Bass: ±10dB at 100Hz

Treble: ±10dB at 10KHz

Frequency response
80~16KHz(+1dB,-3dB)
SNR
MIC1-6: 66dB; AUX1-4: 80dB
THD
< 0.5% (at 1KHz, 1/3 rated power)
Phantom power
48V(±2V)
