2 x 20W Mini Stereo Class-D Amplifier (Balanced inputs + Bridge mode) T-220AP

The Details Related Solution Related Cases Related Video Download

Features

* Smart compact size for tabletop or wall mounted design.

* Digital high efficiency mini amplifier.

* Stereo output 20 watts by two channels and bridged output 40 watts

* 2 Mic/line switchable inputs by phoenix connectors and 2 unbalanced aux inputs

by dual RCA type

* Left and right master volume controls over Mic and music, bass and treble tone controls.

* Left and right channel outputs by phoenix connector, bridged or stereo output two

options with switch

* Speaker stereo outputs at 4 ohms/ 8 ohms and speaker bridged output at 8 ohms.

* Built-in limiter for low noise and efficient operation, with limiter on/off switch,

which make it suitable for laptop and iphone input.

* DC 24V power adapter is included.


Specifications

Product Model T-220AP
Frequency Response 50Hz~18KHz (±2dB)
S/N Ratio(line) Better than 85dB
Controls Power switch, volume control
Efficiency 85%
Protection AC fuse, clipping, high temp & short-circuit
Indicators Power
LINE 350mV/10KΩ
MIC Input 5mV/600Ω
Power Supply DC 24V
THD Less than 0.5% at 1KHz, 1/3 rated power
Rated Power Output 2 x 20W (THD10% @ 4Ω1KHz)
Speaker Outputs 4Ω or 8Ω
Finish Panel: steel, black ;Case: SPCC Panel
Input 2 AUX inputs by RCA and 2 MIC/Line inputs by phoenix connectors
Dimensions 230 x 115 x 57mm
