1. Dimming: 0-100% electronic linear dimming, smooth dimming technology without jitter.
2. Strobe: 0-25 times/second electronic strobe, speed adjustable, built-in random strobe or pulse strobe.
3. Color mixing system: RGBW (red, green, blue, white) linear color mixing; 16.8 million colors (0-100% saturation adjustable), built-in macro function.
4. Focusing: Linear electric focusing.
5. Scanning range: X-axis 540° (16-bit precision scanning) electronic error correction, Y-axis 250° (16-bit precision scanning) electronic error correction, precise scanning positioning, signal feedback, absolute position memory.
6. Display interface: It adopts an LCD screen, is equipped with 5 mechanical buttons, and supports a bilingual operating system in Chinese and English.
7. Temperature protection: Built-in NTC temperature control function, which intelligently reduces the output power of the LED when it overheats.
|
Input voltage |
AC 110-240V, 50/60Hz |
|
Rated power |
400W |
|
Power factor |
PF ≥ 0.90 |
|
Light source |
36*10W RGBW four-in-one LED |
|
Average lifespan of light source |
50,000 hours |
|
Color temperature |
6500K |
|
Luminous flux |
15265 lm |
|
Color rendering index |
Ra≥70 |
|
Beam angle |
15°-30° |
|
Spot angle |
15°-60° |
|
Control method |
DMX512 protocol, with built-in master-slave mode, auto-run mode, voice control mode, and manual control mode. |
|
Channel modes |
Simplified mode 9CH, Standard mode 16CH |
|
Shell material |
High-temperature resistant plastic + molded alloy material + heat dissipation method/air cooling |
|
Power interface |
1 power input interface |
|
Signal interfaces |
1 DMX512 input interface, 1 DMX512 output interface |
|
Operating ambient temperature |
-10℃ to 45℃ |
|
Protection rating |
IP20 |
|
Product dimensions (L×W×H) |
329×220×450mm |
|
Packaging dimensions (L×W×H) |
425×295×390mm (carton) |
|
Gross weight of packaging |
9.35kg |
|
Product net weight |
8.85kg |
