Digital Mixer Amplifier with MP3/TUNER/Bluetooth, for background music playback of small and medium-sized indoor venues such as small and medium-sized supermarkets, shopping malls, and leisure cafes.
* Standard rack mounted design (1U), exquisite SMT process design.
* With MP3 function module, adopt LCD display, support playback of various file formats in USB disk such as MP3, WMA, APE, FLAC, WAV, and AAC; with TF card, support mobile phone Bluetooth function, and can display song names.
* Support mp3/TUNER/Bluetooth remote control function.
* 1 channel EMC input, 2 channel AUX input, 4 channel MIC input.
* Channel priority function EMC>MIC1>MIC2, MIC3, AUX1, AUX2.
* Each input has independent volume adjustment, and the total volume has treble, bass adjustment and volume control function.
* The device is equipped with level indication, overload and protection indicators.
* The device has good self-protection such as short circuit, overload and overheating.
* Two output modes: constant voltage output 100V, constant resistance output 4-16Ω.
* The high-efficiency energy-saving switching power supply is perfectly combined with the high-energy saving and ultra-stable design of class D digital power amplifier.
* Wide voltage supply: 180V-240V can work normally.
* Standby power supply 24V switching without delay (optional).
|
Model |
TIPAK-60DTB |
TIPAK-120DTB |
|
Output |
4-16Ω, 100V |
|
|
RMS Power |
60W |
120W |
|
Input Sensitivity And Impedance |
MIC1,2,3,4 input: 5mV / 600Ω balanced European terminal; AUX1,2 input: 350mV / 10KΩ unbalanced RCA connection terminal; EMC input: 775mv / 10KΩ unbalanced 6.3 connection terminal |
|
|
Output Sensitivity & Source Impedance |
MIX OUT: 1000mV / 470Ω unbalanced RCA connector |
|
|
Tone |
Bass: ± 10dB at 100Hz; Treble: ± 10dB at 10KHz |
|
|
Frequency Response |
80Hz ~16KHz (+ 1dB, -3dB) |
|
|
SNR |
MIC1,2,3: 66dB; AUX1,2: 85dB |
|
|
THD |
< 0.05% (at 1KHz, 1/3 rated power) |
|
|
Mute Function |
MIC 1 is prior to MIC2-4, AUX1-2 audio input; EMC is prior to all audio inputs |
|
|
Channel Crosstalk Attenuation |
≥50dB |
|
|
Heat Dissipation |
Side-in and rear-out forced fan cooling; fan starts automatically when the device is turned on; infinitely variable speed |
|
|
Protection |
Overheat protection, overcurrent protection, short circuit protection |
|
|
Power Supply |
AC ~ 220V / 50Hz |
|
|
Power Consumption |
120W |
180W |
|
Dimension |
484 ×300 × 44mm |
|
|
Weight |
3.5Kg |
3.7Kg |
