* Optical system: Adopt high temperature resistant and high transmittance optical glass optical lens group (5 layers of coating), φ155mm aperture light output lens.
* Dimming: 0-100% electronic linear dimming, jitter-free smooth dimming technology.
* Strobe: 0-25 times/second electronic strobe, speed adjustable, built-in random strobe or pulse strobe.
* Focus: Manual focus.
* Color mixing system: Warm white + cool white 2 colors can be linearly mixed to adjust the color temperature.
* Graphic cutting disc: 4 independent manual cutting discs, cutting at any angle to adjust the spot shape.
* Display interface: 1.5-inch blue screen LCD display; equipped with 2 manual knobs.
|
1. Input voltage |
AC 110-240V, 50/60Hz |
|
2. Rated power |
210W |
|
3. Power factor |
PF≥0.98 |
|
4. Light source |
200W LED (CW+WW) |
|
5. Average lifespan of light source |
50000H |
|
6. Color temperature |
2700K-6500K |
|
7. Color tolerance |
SDCM≤3 |
|
8. Luminous flux |
3600lm |
|
9. Color rendering index |
Ra≥95 |
|
10.Beam angle |
10°-20° |
|
11. Control method |
DMX512 protocol, RDM protocol, built-in master-slave mode, manual control mode |
|
12. Channel Mode |
Standard mode 1CH |
|
13. Shell material |
die-cast aluminum |
|
14.Power interface |
1 power input interface, 1 power output interface |
|
15.Signal interface |
1 DMX512 input interface, 1 DMX512 output interface |
|
16. Working environment temperature |
-10℃-45℃ |
|
17. Protection level |
IP20 |
|
18. Product dimensions (L×W×H) |
928×330×316mm |
|
19. Packing size (L×W×H) |
940×315×330mm (carton) |
|
20. Gross weight of packaging |
15.8Kg |
|
21. Net weight of product |
14.7Kg |
Please leave a message if necessary, we will contact you as soon as possible!
