Description:
* It is also called a directional antenna. In the active state, the antenna can receive signals of about 100-150 meters in a straight line.
* With amplifier gain adjustment gear, when the amplification factor is extremely high, the self-excitation phenomenon can be prevented by adjusting the lower gear.
* With wide antenna receiving frequency band, it can receive frequencies of 470-950MHZ.
* Easy and convenient to install.
Feature:
|
Antenna frequency range |
470～950MHz |
|
Amplifier gain |
8.0dBi |
|
Antenna VSWR |
≤2.0 |
|
Antenna polarization method |
Linear polarization |
|
Input resistance |
50Ω |
|
Amplifier gain level |
4 (-6dB, 0dB, 6dB, 12dB) |
|
Connector port |
BNC connector |
|
Operating temperature |
-30～+60℃ |
|
Amplifier OIP3 |
＞38dBm |
|
Directivity |
90° |
|
Supply voltage |
DC 8～12V |
|
Power supply |
Powered by receiver or distributor |
|
Antenna size |
305×290×35.3mm |
|
Net weight |
0.282±0.005kg |
