VA-6ZRM Voice Evacuation Microphone

The Details Related Solution Related Cases Related Video Download



itc New Product VA-6ZRM with Voice Evacuation Microphone


Features:


* Support 40 zones, 6 group button paging.

* Support zone configuration to any grouping.

* Support consecutive paging for any controller of 1 ~ 6 zones.

* Support line input / microphone output. And output volume is adjustable.

* Remote microphone paging priority can be configured.

* Display the zone status of the associated controller in real time.

* upport 24 DC power supply, POE power supply.

* The system supports up to 28 remote microphones.


Performance index


Analog audio


MIC microphone input
Sensitivity
10MV±1mV
Frequency response
200Hz~10kHz
Input impedance
≥1kΩ
LINE unbalanced line audio input
Sensitivity
775MV±50mV

Frequency response


80Hz~16kHz
Impedance
≥10kΩ




Balanced line output


lAmplitude
1000MV±50mV
lDistortion
<0.3%, 1 kHz
lFrequency response
200Hz~10kHz
lOutput impedance
470Ω
lSNR
>60dB


Communication


CAN interface
lRemote MIC console CAN interface
lBaud rate 100Kbps
lSupport up to 32 remote MIC consoles




Mechanical indicators


Size (L × W × H)
197 * 115 * 44 mm
Net weight
About 1.2KG
Installation
Desktop or 19-inch cabinet
Color
Black


Environmental requirements


l Operating temperature
+5°C ~ +40°C
l Storage temperature
-20 ° C ~ +70 ° C
l Relative temperature
<95%
