Feature:
* Composed of a 5-inch subwoofer unit and a 1-inch dome tweeter.
* Designed with ABS+PC injection molding, suitable for all-weather use.
* Equipped with an aluminum mesh grille and an acoustic sound-permeable sponge inside to prevent dust and water droplets from damaging the speaker unit.
* Precise two-way crossover design is adopted to optimize the frequency response and the mid-range expressiveness of the vocal part.
* With constant resistance and constant voltage selection function. With a U-shaped bracket, it is convenient for engineering installation.
* Suitable for indoor and outdoor fixed installation; applied to BGM broadcasting applications in theme parks, scenic spots and other cultural tourism sound reinforcement scenarios.
Specification:
|
Model |
TW-775K |
|
Speaker type |
Plastic wall mounted speaker |
|
Rated power (100V) |
5W/10W/20W/40W/constant resistance 8Ω, 40W |
|
Rated power (70V) |
5W/10W/20W/40W/constant resistance 8Ω, 40W |
|
Nominal impedance |
2000Ω/1000Ω/500Ω/250Ω/122Ω constant resistance 8Ω |
|
Frequency range (-10dB) |
80Hz-20kHz |
|
Sensitivity (1M/1W) |
90dB±3dB |
|
Maximum SPL |
109dB |
|
Coverage angle (-6dB) |
100°(H)×80°(V) |
|
Subwoofer |
5-inch subwoofer×1 |
|
Tweeter |
1-inch tweeter×1 |
|
Net weight |
3.3kg |
|
Dimension (H×W×D) |
278×170×172mm |
