TS-208M Ceiling Speaker

The Details Related Solution Related Cases Related Video Download

Feature:


*  Composed of a 8-inch subwoofer and a 1-inch rotatable dome tweeter.

*  With a coaxial 2-way design, the precisely engineered crossover optimizes the response of the vocal section.

*  The tweeter and subwoofer are designed with an inclined angle, which effectively solves the problem of insufficient high-frequency directivity and facilitates on-site debugging for users.

*  Using injection molded PP diaphragm to achieve high-fidelity reproduction of human voice.

*  Frameless magnetic mesh cover design.

*  Built-in adjustable directional tweeter.

*  Suitable for use in indoor places such as high-end conference rooms, hotels and clubs.


Specification:


Model

TS-208M

Speaker type

Ceiling speaker

Rated power

100W

Maximum power

200W

Nominal impedance

8Ω

Frequency range (-10dB)

55Hz-20kHz

Sensitivity (1M/1W)

93dB±3dB

Maximum SPL

116dB±3dB

Coverage angle (-6dB)

0-120°

Subwoofer

8-inch subwoofer×1

Tweeter

1-inch tweeter×1

Net weight

2.8kg

Dimension (H×W)

145×277mm

Opening size

248mm
